Watts LFM1115-3 3 - Part of the LFM115-3 Series
This 3 inch angle pattern class 150 flanged epoxy coated pressure reducing control valve, model 115-3, is designed to automatically reduce a fluctuating higher inlet pressure to a constant lower downstream pressure regardless of varying flow rates. The quick closing action of the valve limits possible damaging high inlet pressure from passing through the valve to downstream piping. Piloted with a check feature to close the valve when downstream pressure becomes greater than upstream pressure.
Features- Angle pattern
- Class 150 flanged
- Epoxy coated
- Copper tubing/brass fittings
| Specifications | |
|---|---|
| ArmorTek Technology | No |
| Brand | Watts |
| EAN | 098268048001 |
| Lead Free | YES |
| Part Number | V5089-24 |
| Series | LFM115-3 |
| Warranty Name | Standard Watts Warranty |
- Submittal Package - Automatic Control Valve LFM115-3
