Watts - FD-200-ER - Floor Drain with Extended Rim Strainer

The Watts FD-200-ER is a specification-grade, epoxy-coated cast iron floor drain engineered for robust commercial and institutional environments. It features an anchor flange, dual weepholes for perimeter seepage control, and an adjustable round nickel-bronze extended rim strainer for enhanced surface coverage and anti-splash performance. The standard connection is a no-hub outlet for compatibility with conventional drainage piping.

Key Features

• Epoxy-coated cast iron body with anchor flange for durability and secure installation

• Adjustable round nickel-bronze strainer with extended rim design to prevent splashback and improve surface drainage

• Dual weepholes and reversible clamping collar to manage perimeter seepage and protect adjacent surfaces

• No-hub outlet (standard) with options for push-on or inside-caulk connections to accommodate installation demands

• Crafted for commercial on-grade use where high performance, ease of maintenance, and effective drainage are required

Downloads:

• Specification Sheet
